FLITSUS-1500-L-835-2-90-BL
Technical specifications
Light Source
LED
CCT
3500k
CRI
80
Switching type
DALI
Connected load
30.60 W
Lumen output
4,835.50 lm
Efficiency
158.0 lm/W
Technical data
Mains voltage
220 - 240V AC, 50/60Hz
Connection method
Plug-in terminal
Switching type
DALI
Socket
20
Protection class
I
Ambient temperature
0 to +30 °C
Light Source
LED
CCT
3500k
CRI
80
Connected load
30.60 W
Lumen output
4,835.50 lm
Efficiency
158.0 lm/W
Ripple
1 %
DALI address
1
Inrush current
6 A
Inrush time
800 μs
Optical system
Lenses
Optical part material
PMMA
Housing material
Aluminium
Surface finish
Powder coated
Width
62.00 mm
Height
57.00 mm
Length
1,500.00 mm
Weight
1.80 kg
Service lifetime (L80 B10)
60 000 h
Warranty
5 years
Housing color
Dimmensions and light distribution
